Item unit Parameter
Products name 50m3 & 60m3 lpg storage tank
Products number CLG1600-10
Filling medium LPG(propane)
Overall dimensions mm9182*2728*3318 & 10962*2728*3318(L*W*H)
Tank size (innerdiameter*thickness*length)mm DN2700*14*9182/ 10962
Volumem 350 m3 &60m3
Net weight（ Kg） 10640 & 11470
Volumem 350 m3 &60m3
Net weight（ Kg） 10640 & 11470
Designing pressure Mps1.77
Working pressure Mps≤1.6
Working temperature ° C≤50
Hydraulic test pressure Mps2.22
Air test pressure Mps1.77
Air test pressure Mps1.77
Material of tank and accessory Q345R,16MnIII
standard GB150 Steel pressure vessel, pressure vessel safety technology to monitor the procedur
esaccessory：
1.Safety valve
2. magnetic flap liquid level gauge
3.pressure gauge
4.thermometer
5.cut-off valves
etc(the marked price is not including the accessory).
